Hãng Sản Xuất: MSI
Tình Trạng: Mới và Fullbox 100%
Bảo Hành: 36 Tháng
Sản phẩm |
Mainboard - Bo mạch chủ |
|
Tên Hãng |
MSI |
|
Model |
MEG Z490 UNIFY | |
CPU hỗ trợ |
Supports 10th Gen Intel® Core™ and Pentium® Gold / Celeron® processors for LGA1200 socket |
|
Chipset |
Intel® Z490 Chipset |
|
RAM hỗ trợ |
4 x DDR4 memory slots, support up to 128GB
Supports Dual-Channel mode Supports non-ECC, un-buffered memory Supports Intel® Extreme Memory Profile (XMP) |
|
Khe cắm mở rộng |
|
|
Hỗ trợ đa card màn hình |
|
|
Lưu trữ |
SATA2 will be unavailable when installing M.2 SATA SSD in the M2_1 slot. SATA5 & SATA6 will be unavailable when installing M.2 SATA/PCIe SSD in the M2_2 slot. Before using Intel® Optane™ memory modules, please ensure that you have updated the drivers and BIOS to the latest version from MSI website. |
|
RAID |
Supports RAID 0, RAID1, RAID 5 and RAID 10 for SATA storage devices Supports RAID 0, RAID 1 and RAID 5 for M.2 PCIe storage devices |
|
USB |
Intel® Z490 Chipset
ASMedia® 3241 chipset
|
|
Âm Thanh |
Realtek® ALC1220 Codec + ESS SABRE9018Q2C combo DAC
|
|
LAN |
1x Realtek® 8125B 2.5G LAN controller |
|
WiFi & Bluetooth |
Intel® AX201
Only support windows 10 64-bit |
|
Cổng kết nối ( I/O bên trong) |
1x 24-pin ATX main power connector 2x 8-pin ATX 12V power connectors 6x SATA 6Gb/s connectors 3x M.2 slots (M-Key) 1x USB 3.2 Gen 2 10Gbps Type-C port 1x USB 3.2 Gen 1 5Gbps connector (supports additional 2 USB 3.2 Gen 1 5Gbps ports) 2x USB 2.0 connectors (supports additional 4 USB 2.0 ports) 1x 4-pin CPU fan connector 1x 4-pin water-pump connector 6x 4-pin system fan connectors 1x front panel audio connector 2x system panel connectors 1x Chassis Intrusion connector 1x slow mode jumper 1x power button 1x reset button 1x 4-pin RGB LED connector 2x 3-pin RAINBOW LED connectors 1x 3-pin CORSAIR LED connector |
|
Cổng kết nối ( I/O Phía sau) |
|
|
Kích cỡ |
Micro-ATX Form Factor 9.6 in. x 9.6 in. (24.4 cm x 24.4 cm) |
